I added percentages for grades in the student view, as well as the student’s overall grade in the course so far.

I modified the grades controller to get the overall grade, and I modified the view to display the percentages.

This further addresses issue 11.

I’ve been working on making DPLMS compatible with IE, since we originally developed with Firefox and Safari. IE handles CSS slightly differently than the other browsers, particularly when it comes to making an assumption about a rule. So I went through and made rules more explicit, instead of letting the browsers interpret in their own way. Also, adding a Doctype declaration on top of the header helped out quite a bit. It’s something that’s easy to forget to include, but IE behaves very differently with javascript and css when a valid Doctype is defined.

I just committed the changes, but they aren’t live on the demo site yet, as there is still some more thorough testing to do.

This addresses Issue 13.

The ability to have structured course content stored in the database and maintain efficient lookups of what files are in what directories as well as traversing the path to the tree root is a little complicated.

Each entry in the database has left and right counts as well as a tag indicating whether or not it is a directory (which isn’t entirely necessary). For example, if you have a root node and two children, the database might look like this:

ID / NODE NAME / LEFT / RIGHT / DIR
1 / Root / 1 / 6 / 1
2 / Left Child / 2 / 3 / 0
3 / Right Child / 4 / 5 / 0


This requires modifying existing rows when adding new data, but given that the changing of content is a much less common occurrence than accessing data, it makes sense for the cost to be up front. This is essentially a modified preorder traversal data structure. One side effect is the queries are a bit harder to write than an adjacency list data structure. For instance, returning just the immediate child nodes of any parent node requires the following SQL query:

SELECT node.name, node.id, node.lft, node.file_name, node.file_ext, node.dir, (COUNT(parent.name) - (sub_tree.depth + 1)) AS depth
FROM section_content AS node,
section_content AS parent,
section_content AS sub_parent,
(
SELECT node.name, (COUNT(parent.name) - 1) AS depth
FROM section_content AS node,
section_content AS parent
WHERE node.lft BETWEEN parent.lft AND parent.rgt
AND node.lft = ?
AND node.section_id = ?
AND parent.section_id = ?
GROUP BY node.name
ORDER BY node.lft
)AS sub_tree
WHERE node.lft BETWEEN parent.lft AND parent.rgt
AND node.lft BETWEEN sub_parent.lft AND sub_parent.rgt
AND sub_parent.name = sub_tree.name
AND node.section_id = ?
AND parent.section_id = ?
AND node.lft != '1'
GROUP BY node.name
HAVING depth = 1
ORDER BY node.lft


Issue 15 noted that uploading course content did not work. This has been resolved for the simple case (uploading to a single section). Uploading to all sections in a course will require the addition of a loop.

Based on a suggestion by Ryan Govostes, I have implemented salted passwords. If the database is compromised by some sort of attack — SQL injection, or otherwise — the attacker will be unable to use a pre-made collision table.

Now, there is an application salt in addition to a per-user salt. The idea behind the application-wide salt is that if the database is compromised but the application data is not, it will be extremely difficult, if not impossible to generate collisions against the hashed passwords. The per-user salt is stored in the database and increases the complexity of collision-generation while not significantly affecting application performance.

Our subversion repository, bug-tracker and wiki are all hosted on Google Code.

The project is hosted here.
